Φ8mm Measuring Aperture Integrating Colorimeter NR200 to Develop
Multifaceted Colors in Duochrome Cosmetics
There’s a lot of room for error in creating cosmetics, as
development hinges on interference pigments. These pigments
“interfere” with an existing color and if used incorrectly, the end
result could be lackluster. As such, base color is the key to
establishing a cosmetic that uses interference pigments to their
full advantage. By using Φ8mm Measuring Aperture Integrating Colorimeter NR200, cosmetics manufacturers can develop a base color that works
perfectly with interference pigments and move that color into mass
production.
Brief Introduction
Φ8mm Measuring Aperture Integrating Colorimeter NR200 to Develop
Multifaceted Colors in Duochrome Cosmetics is another mainstream brand Integrating Colorimeter introduced by 3nh which has synthesized the advantages of ten more
traditional imported colorimeters and has experienced ten thousands
tests and applied many innovative technologies. Accurate, Stable,
Exquisite and Affordable!
Main Features
1. Leading Humanity Design and Convenient Operation
One-touch access to measurement interface
Structure design in line with ergonomics
Easy-to-use operating interface
2. Stable Measurement Performance
The repeatability △E is 0.08.
Portable structure design which is more conductive to keeping the
instrument stable when using.
3. Convenient and Fast Locating
Illumination locating is a fast, simple and convenient locating
which created by 3nh.
4. PC Software—Realize More Function Expansion
3nh has the intellectual property of PC software CQCS3. The
corresponding software serial number and password protection are
configured in 3nh colorimeter.
Be able to perform color difference analysis, color difference
cumulative analysis, chromaticity index, color sample database
management, simulating object color, etc.
5. Advanced Power Management Design
3nh is the first enterprise using high capacity Li-ion battery in
colorimeter.
3nh Li-ion battery can be repeatedly charged which will save cost.
Meanwhile, it can measure more than 3000 times on one charge to
ensure the stability of long time measurement.
Technical Specification
| Name&Model | Colorimeter NR200 |
| Illuminating/Viewing Geometry | 8°/D (8° illumination, diffuse Viewing), |
| Observer | CIE 10° Standard Observer |
| Measuring Aperture | Φ8mm |
| Repetitive Error | Standard Deviation within ΔE*ab=0.08 |
| (Calculating Method: Average value of the results of 30
measurements of the standard white plate) |
| Inter-Instrument Error | Within ΔE*ab=0.5 |
| Color Space | CIE L*a*b*C*h, CIE L*a*b, CIE XYZ |
| Color Difference Formula | ΔE*ab, ΔL*a*b*, ΔE*C*h* |
| Measurement Time | 1.5s |
| Measuring Range | L: 0-100 |
| Light Source Type | D65 |
| Light Source Device | LED Blue Light Excitation |
| Light Source Life | 5 years, more than 1.6 million measurements |
| Sensor | Silicon Photoelectric Diode Array |
| Data Storage | 100 Standards, 20000 Samples |
| Data Port | USB |
| Standard Accessory | AC Adapter, Li-ion Battery, Operation Manual, Software CD, USB
Cable, White Calibration Cover, Φ8mm and Φ4mm Measuring Aperture |
| Optional Accessory | Mini-printer, Powder Test Box |
Product Images
Application
Φ8mm Measuring Aperture Integrating Colorimeter NR200 is widely used in Duochrome Cosmetics,Textiles, printing and dyeing, plastic, paint, ink, printing,
paint, spray, chemical, ceramics, shoes, leather, hardware,
furniture, electrical appliances, packaging, and other industries
and color management.
FAQ
1: Q: Is your company accept customization?
A: We accept OEM/ ODM. Any color and any logo is welcome if placed
at least 10pcs.
2: Q:Does your products have warranty?
A: YES, We offer 1 year warranty. Our policy: Is there any quality
problem, First, send the defective machine to us and you bear the
freight. Second, we send back to you free after fixed.
3: Q: After an order placed, when to deliver?
A: It depends on whether we are in stock or not. If we are,
generally we can arrange shipment in 1 days after payment. If not,
it will be decided by factory production.
4: Q: How to place an order?
A: a: send us an inquiry.
b: confirm your wanted products
c: confirm the price and freight and other details
d: finish the payment
e: we arrange the shipment
f: you got your products
