ISO7724/1 Liquid Spectrophotometer YS4580 Accurate Color Measurement Meter for Bleached or Fluorescent White Products

Product Introduction

ISO7724/1 Liquid Spectrophotometer YS4580 Accurate Color Measurement Meter for Bleached or Fluorescent White Products is 45/0 (45 degree ring illumination, 0 degree reception) geometric optical structure in accordance with CIE No. 15 and adopts concave grating spectrometry to accurately measure sample reflectance and various colorimetric data; Equipped with a large measuring aperture of Φ20 mm for traffic signs, color matching, precise color transfer; Built-in GB2893, GB/T18833 standard color, can be manually customized polygonal rectangle tolerance, one button to realize the measurement of traffic road signs, marking lines, reflective film brightness factor and chromaticity coordinates. For Bleached or Fluorescent White Products, the instrument has high accuracy and high stability.

Main Features

• 1. Beautiful appearance and perfect combination with ergonomic structure design;
• 2.45/0 geometric optical structure, in accordance with CIE No.15, GB/T 3978, GB 2893, GB/T 18833, ISO7724/1, ASTM E1164, DIN5033 Teil7, GB 2893, GB/T 18833;
• 3.USB/Bluetooth 4.0 (compatible with 2.1) dual communication mode, more adaptable;
• 4. Large-capacity storage space, can store more than 30,000 test data;
• 5.Φ20mm aperture adapt to larger samples or uneven samples;
• 6. Adopt high-life and low-power combined LED light source, including UV/excluding UV;
• 7. High electronic hardware configuration: 3.5-inch TFT true color screen, capacitive touch screen, concave grating, 256-pixel dual-array CMOS detector, etc.;
• 8.Built-in standard polygon tolerance setting and specific traffic sign gamut, especially suitable for traffic signage brightness factor and chromaticity performance judgment;
• 9. Two standard observers, multiple light source modes, multiple color systems, and a variety of standard colorimetric indicators to meet the needs of various customers for color measurement;
• 10. PC software has powerful function extensions;

Technical Specifications

Images

Applicable Industries

The grating spectrophotometer YS4560 can easily realize the accurate transmission of color, and can also be used as the detection equipment of the accurate color matching system; it is used for accurate color measurement and quality control of Bleached or Fluorescent White Products, traffic road signs, plastic electronics, paint ink, textile and garment printing and dyeing, printing, ceramics, etc.; There is a separate UV source for fluorescence sample measurement. Traffic road marking plastic coatings food laboratory.
