YS3020 USB RS-232 Paint Matching Spectrophotometer Customized
Aperture For Fiber Metallic Paint
If you hope to take on clients with rigorous color quality control
standards, spectrophotometric analysis is already essential since
without this capability, you’ll be unable to compete for bids.1
And since powder coating is now being chosen over traditional
liquid VOC paint due to its economic, environmental, mechanical,
safety, and efficiency advantages, we’re seeing more and more
applications that once used liquid paint beginning
convert—including applications for a number of designer and
specialty products. Companies like Austrian furniture designer
Finima have already made the switch to powder coating, and winning
bids for similar high-end applications will require you to have
delicate control over product color—as well as the ability to offer
unique color configurations.
About 3nh
Shenzhen Threenh Technology Co., Ltd. is a high-tech enterprise. We
research, develop, produce and market photoelectric detection
products in photoelectric detection technology field and color
management field.After years of intensice research, 3nh has
launched NS series spectrophotometer and NH, NR series colorimeter,
ISO12233 resolution test chart, optical image test solution and
specific standard illuminant which are widely used in plastic,
electronic, paint, ink, textile, garment, printing and dyeing,
food, medical, cosmetic, optical image test industries and the
field of scientific research, school and laboratory. Our products
are exported around the world. We can provide customization service
which has been well received by customers.
3nh cherishes talents, focuses on talents. Company brings together
many of high-level, high educated professionals. Among them,
undergraduate academic staffs of the total number of company
accounted for more than 80%; postgraduate staffs of the total
number of company accounted for 30%. It involves the fields of
photometry, electronic circuit, embedded system, photoelectric
detection, mechanical structure design, optical design, application
software, lighting technology electronic commerce and internet. 3nh
team has strong capability to design, develop and produce on its
own. The company has a large number of innovation patents, core
technologies and intellectual property rights of 3nh products.
3nh adheres to “people-oriented, customer first, technological
innovation, sustainable development” business philosophy to meet
customer demand continuously, to create value for customers and to
achieve win-win situation and common development.
Product Introduction
YS3010, YS3020, YS3060 are domestically produced grating Paint Matching Spectrophotometer ndependently developed by 3nh.The instruments are stable, accurate
in color measurement and powerful in function. They led the way in
the field of portable grating spectrophotometers. Grating
spectrophotometers are widely used in scientific research
institutions and laboratories in the fields of plastic electronics,
paint inks, textile and garment printing,printing paper products,
automobiles, medical, cosmetics and food.
Under the D8 geometric optical illumination recommended by CIE, the
grating spectrophotometer can accurately measure the SCI and SCE
reflectance data of the sample/fluorescent sample, and can
accurately measure various color difference formulas and color
indices in multiple color spaces. And expression. With the
instrument, it is easy to transfer the color accurately, and it can
also be used as a detection device for a precise color matching
system. The instrument is also widely used in the control of color
quality in various products. The instrument is equipped with
high-end color management software, connected to the computer for
more expansion.
YS series spectrophotometer is the most accurate instrument in our
portable colorimeter. It is designed according to the principle of
spectroscopic type. Different from ordinary colorimeter, the
colorimetric colorimeter has high precision and increasing
versatility due to it. The corresponding reflectivity at each
wavelength can be measured, with a complete spectral curve, so it
is suitable for complex color analysis, and of course the price is
relatively expensive. Ordinary colorimeter is designed according to
the tristimulus value, relatively low price, small size, superior
flexibility and easy operation.
YS series spectrophotometer includes three models,
YS3010/YS3020/YS3060, according to the actual application, such as
measuring the size of the product, whether the product is flat, the
convenience of operation, the environment used, can not be
excellent analysis report To choose the one that best suits your
measurement needs.
Technical
| Model | YS3020 spectrophotometer |
| Illumination/observation system | Reflect: di:8°,de:8°(diffused illumination,8-degree viewing angle) |
| Integrating sphere Size | Φ48mm |
| Light Source | Combined LED Light |
| Sensor | 256 Image Element Double Array CMOS Image Sensor |
| Wavelength range | 400~700nm |
| Wavelength pitch | 10nm |
| Reflectance range | 0~200% |
| Measuring Aperture | 4mm/8mm/1*3mm |
| Color Space | CIE Lab, XYZ, Yxy, LCh, CIE LUV, Hunter LAB |
| Color difference Formula | ΔE*ab,ΔE*uv,ΔE*94,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*00v,ΔE(Hunter) |
| Other Chromaticity Data | WI(ASTM E313, CIE/ISO, AATCC, Hunter), |
| YI(ASTM D1925, ASTM 313),TI(ASTM E313, CIE/ISO), |
| Metamerism Index MI,Staining Fastness,Color Fastness,Color
Strength, Opacity |
| Observer | 2°/10° |
| Illuminant | D65, A, C, D50, D55, D75, F1, F2, F3, F4, F5, F6, F7, F8, F9, F10,
F11, F12 |
| Display Data | Spectrogram/Values, Samples Chromaticity Values, Color Difference
Values/Graph, PASS/FAIL Result, Color Offset |
| Measurement Time | 1.5s |
| Repeatability | Spectral Reflectance: standard deviation within 0.1%(400~700nm:
within 0.2%) |
| Colorimetric Value: Standard deviation within DeltaE*ab 0.04
(Measurement conditions: white calibration plate measured 30 times
at 5 seconds intervals after white calibration was performed.) |
| Inter Instrument Agreement | Within DeltaE*ab 0.2 (Average for 12 BCRA Series II color tiles) |
| Dimension | L*W*H=184*77*105mm |
| Weight | 600g |
| Battery | Li-ion battery. 5000 times within 8 hours. |
| Lamp Life | 5 years, more than 1.6 million measurements |
| Display Screen | TFT 3.5inch, Capacitive Touch Screen |
| Interface | USB/RS-232 |
| Data Memory | Standard 2000 Pcs, Sample 20000 Pcs |
| Operating Temperature | 0~40℃(32~104°F) |
| Storage temperature | -20~50℃(-4~122°F) |
| Standard Accessory | Power Adapter, Built-In Li-ion Battery, User Guide, PC Software,
White and Black Calibration Cavity, Dust Cover |
| Optional Accessory | Micro Printer, Powder Test Box |
| Notes | The specifications are subject to change without notice. |
Applicable Industries
3nh handheld Paint Matching Spectrophotometer can easily achieve color transferring , and be used as a precision
instrument for color matching system. It's widely used in plastics,
electronics, painting, ink, textile and garment, printing and
dyeing, printing paper, automotive, medical, cosmetics and food
industries, scientific research institutes, schools and
laboratories.
Images
