3nh Economic Gloss Measurement Instruments Aluminum Oxidation Stone Gloss Meter HG60

Product Description

1. Brief Introduction of Digital Gloss meter HG60

1) 3nh HG60 single-angle economical Gloss Measurement Instruments , whose complete proprietary intellectual property rights are fully owned by 3nh, was researched and developped complying with the international standard ISO2813 and China national standard GB/T9754, also the standard ASTM D 523 and ASTM D 2457.

2) Features

1. 60° angle for semi gloss

2. Concise appearance, feel good

3. Display 5 sets of measurement data, good for comparison

4. Built-in lithium ion rechargeable battery

5. Basic model measurement can meet basic glossiness testing requirements

6. Connect to PC, more extend functions

7. One button for all angles measurement at the same location

8. Comply with international standards

9. Stable performance, easy to read data.

3)Specifications for Digital Gloss Measurement Instruments HG60

GQC6 Software Introduction:

GQC6 software is used with 3nh gloss meter for PC connection, measurement, data management, data export, print reports, etc.

4)Application for Digital Gloss meter HG60

Paint,Paper,ink,Plastic,film,Bamboo,flooring,Stainless steel,Aluminum oxidation,Stone,Ceramic tile,Leatherwear...

5)More pictures for Digital Gloss meter HG60

Packaging & Shipping
Packing Material : Nylon box with carton box
Packing Size 29*19*10CM
Packing Weight:1KG
Delivery time: Within 1 working day after payment received.

How many different angles shall we have for gloss meter?

High Gloss - 20 or micro-gloss 20
A smooth and highly polished surfaces reflect images distinctly. The incident light is directly reflected on the surface, i.e. only in the main direction of reflection. The angle of incidence is equal to the angle of reflection.

Semi Gloss - 60 or micro-gloss 60
On rough surfaces the light is diffusely scattered in all directions. The image forming qualities are diminished: A reflected object does no longer appear brilliant, but blurred.
The more uniform the light is scattered, the less intense is the reflection in the main direction and the duller the surface will appear. We have several models with 60 degree, such as NHG60, HG60, etc.

High and Semi Gloss - 60/20
One Gloss meter does double work.
Low Gloss or Mat - 85 or micro-gloss 85
On very rough surfaces the light is diffusely scattered in all directions. The image forming qualities are much diminished: A reflected object no longer appears brilliant, but almost non-existent.

Measure all three modes - TRI-gloss (20/60/85)
When one requires measuring all three types of surfaces described above, we have two gloss meters that simultaneously measures all three geometries. They are NHG268 and HG268 with 20/60/85.
