2.8 Inch Display Color Matching Spectrophotometer NH300 for bath
shampoo and conditioner testing
Why use a colorimeter
When people observe the color of a product with the naked eye, the
color information of the product can only be described in an
abstract language. This is a certain inconvenience for industrial
color communication. Therefore, in order to better detect the color
and improve the color quality of industrial products, industrial
production now uses precision colorimeter to measure the color
information of the product. The purpose is to quantify the abstract
color into specific color data, so whether it is detection or
analysis or communication has become easier.
Brief Introduction
NH300 digital Color Matching Spectrophotometer is the most convenient colorimeter which is attractive in price and
quality. It is widely used in R&D, quality control and
production management departments. 3nh colorimeter has the ability
to measure color difference accurately and quickly. It is equipped
with quality management software which can measure color difference
easily and accurately. Meanwhile, it can connect with computer and
realize more functions.
Specifications of NH300 Colorimeter
| Model Number | NH300 |
| Illuminating/Viewing Geometry | 8°/D (8° illumination, diffused viewing angle) |
| Measuring Aperture | Φ8mm |
| Integrating Sphere | Non |
| Locating Method | Illumination Locating |
| Repetitive Error | Standard deviation ΔE*ab≤0.07 (Measurement Conditions: White
calibration plate measured 30 times at 5 seconds intervals after
white calibration performed.) |
| Inter-Instruments Error | ΔE*ab≤0.4 |
| Wavelength Range | Non |
| Wavelength Pitch | Non |
| Reflectance Range | Non |
| Color Space | CIE L*a*b*C*H*, CIE L*a*b |
| Color Difference Formula | ΔE*ab, ΔL*a*b, ΔE*C*H |
| Display Data | Colorimetric Value, PASS/FAIL Result |
| Other Chromaticity Data | Non |
| Observer Angle | 10° |
| Light Sources Type | D65 |
| Light Source Device | LED Blue Light Excitation |
| Light Source Life | 5 years, More than 1.6 million measurements |
| Sensor | Silicon Photoelectric Diode Array |
| Measuring Time | 1.5s |
| Data Storage | 100 Standards, 20000 Samples |
| Data Port | USB |
| Display Size | TFT 2.8" |
| Touch-Screen | Non |
| Operating Temperature | 0~40℃ (32℉~104℉) |
| Storage Temperature | -20℃~50℃ (-4℉~122℉) |
| Humidity | 0~85%, No condensation |
| PC Software | CQCS3 |
| Weight | 500g |
| Dimension | 205*70*100mm |
| Battery | Large Capacity Li-ion Battery |
| Standard Accessory | Power Adapter, Li-ion Battery, Operating Instruction,
CD-ROM(containing color management software), USB Cable, White
Calibration Plate, Φ8mm Measuring Aperture |
| Optional Accessory | Universal Test Components, Micro-Printer, Powder Test Box |
| Certificates | CE & RoHS & TUV & FCC & ISO9001 |
Main Features
1. Leading Humanity Design and Convenient Operation
Auto White and Black Calibration at Startup
Structure Design in line with Ergonomics
Easy-to-use Operation Interface
2. Stable Measurement Performance
The average fluctuation of △E is less than 0.07, actually more in
0.03~0.06.
Portable structure design which is more conductive to keeping the
instrument stable when using.
3. Convenient and Fast Locating
Illumination locating is a fast, simple and convenient locating
function which is the original function by 3nh.
4. PC Software—Realize More Function Expansion
3nh has the intellectual property of PC software. The corresponding
software serial number and password protection are configured in
3nh colorimeter.
Be able to perform color difference analysis, color difference
cumulative analysis, chromaticity index, color sample database
management, simulating object color, etc.
5. Advanced Power Management Design
3nh is the first enterprise using high capacity Li-ion battery in
colorimeter.
3nh Li-ion battery can be repeatedly charged which will save cost.
Meanwhile, it can measure more than 3000 times on one charge to
ensure the stability of long time measurement.
Applicable Industries
3nh colorimeter are widely used in plastic, metal, electronic,
paint, ink, textile, garment, printing and dyeing, food, medical,
cosmetic, automotive, toy...industries.
